Spaver Signaty X IR Helmet Light

Differentiation of Signaty X

Multi wireless communication(Short-range Wireless Communication+GPS/RTC+Mesh)
Maintain synchronized pattern with Short-range Wireless Communication and GPS/RTC
Mesh communication(relay between receivers) synchronization provide range expansion
Able to use multiple light source (RGB LED+IR, RGB LED+White LED) simultaneously
42 IR/LED Pattern synchronization and auto-sync (Up to 252 with additional equipment)
Pattern synchronization data is transmitted with 256bit encryption

Spaver Signaty X IR Helmet Light

Signaty X IFF IR Helmet Light

5 Color LED (IR, Red, Green, Blue, White)
9 lamps of 5 colors (IR x 4, RGB LED x 2, White LED x 2, High brightness white LED x 1
High strength polycarbonate dome cover material applied
Pattern programming using CDS without additional equipment
Up to 5km visibility with LED and NIR

Spaver Signaty X IR Helmet Light

IR light made with Korean technology

Synchronization using short-range communication method for both outdoor and indoor environments.
IR can be replaced with SWIR or IR+SWIR upon request
42 pattern synchronization using on board EEPRom without additional equipment
Five group-specific strobe and strobe auto-sync function
Able to operate with one hand, vibration feedback for confirmation
Distress beacon(SOS signal in Red LED or IR) and frontal high brightness flashlight mode
Up to 130 hours of operation using AA batteries (LED 130H / IR 125H)
Low battery alert
Korea Domestic production and A/S

Spaver Signaty X IR Helmet Light

Certifications

Brightness and duration : LED 130 hours, IR 125 hours(In-house tested)
tection Range: Up to 5 km (based on visible light / in-house test results)
Drop : KS C IEC 60068-2-31:2008 (1.5m)
Dustproof/Dust: MIL-STD-810G:2008, Method 510.5, Procedure I (Dust)
Dustproof/Sand: MIL-STD-810G:2008, Method 510.5, Procedure II (Sand)
Dustproof : MIL-STD-810G : 2008 METHOD 510.5
High temperature storage/operation : MIL-STD-810G:2008 METHOD 501.5
PROCEDURE Ⅰ(23~63℃)/PROCEDURE Ⅱ(23~43℃)
High temperature storage/operation : MIL-STD-810G:2008 METHOD 502.5
PROCEDURE Ⅰ(-33~23℃)/PROCEDURE Ⅱ(-32~23℃)
KC Certified (BO5R392-2112B)

As of October 29, 2024

Brightness and duration

Inhouse tested (LED 130 hours, IR 125 hours)

Drop

KS C IEC 60068-2-31 (1.5m)

Waterproof/Dustproof

Waterproof : MIL-STD-810G 512.5 (1m 1hr)
Waterproof : KS C IEC 60529:2013 (1m 1hr)
MIL-STD-810G:2008 METHOD 510.5 PROCEDURE I Dustproof (Dust)
MIL-STD-810G:2008 METHOD 510.5 PROCEDURE II Dustproof (Sand)

High temperature storage/operation

MIL-STD-810G METHOD 501.5
PROCEDURE I (23~63℃)/PROCEDURE II (23~43℃)

Low temperature storage / operation

MIL-STD-810G METHOD 502.5
PROCEDURE I (-33~23℃)/PROCEDURE II (-32~23℃)

Test Passed

KC Certified
(BO5R392-2112B)

5 LED colors and IR

Stores 4 flash patterns

42 IR/LED Pattern synchronization and auto-sync

Up to 5km distance

Manual Download

Catalogue Download

The default settings for starting and stopping the equipment are SW5 [●] Basic Mode and SW4 [○] LED Mode.

Power on/off : Press SW3 to turn on or off.
LED color change : Select SW4 as LED mode and press SW2 to change colors in the order of red > green > blue > white.
Combined LED/IR Mode : After selecting LED mode with SW4, press and hold SW2 to cycle through Combined LED+IR → Combined LED+White LED.
Change brightness : Shortly press the SW1 button. When pressed, it cycles in the following order: 10% > 30% > 60% > 100%.
Change pattern : Press and hold the SW1 button to cycle through the following order: 30 BPM > 50 BPM > Double Pulse > Strobe.
IR Mode : Select SW4 IR mode in default settings.
Flash mode : Select IR mode with SW4, basic mode with SW5, then press and hold SW2.

Quick light mode

■ Flash light mode

Select SW4 as IR mode and SW5 as basic mode, then press and hold SW2 to operate.

■ SOS Light Mode (RED LED)

While pressing SW1, press SW2 briefly 2 times to transmit an SOS pattern signal through the RED LED.

■ SOS Light Mode (IR LED)

While pressing SW1, press SW2 briefly 4 times. Sends out an SOS pattern signal using the IR LED.

Automatic synchronization mode

■ Transmitter

Power ON in basic setting mode
SW5 is in basic mode.
Set the color, brightness, and pattern of the SW4 LED mode or IR mode you want to transmit.
After selecting transmission mode with SW5, synchronization mode is transmitted when the SW2 button LED is set to colorless and the SW1 button LED is set to yellow.

■ Receiving unit

Power ON in basic setting mode
SW4 receiving mode is located.
Press the SW2 button and select the yellow LED to receive synchronization mode.

Programming Sync Mode

■ Transmitter

Power ON in basic setting mode
SW5 basic mode is located.
Set the color and brightness of the SW4 LED mode or IR mode you want to transmit.
After selecting SW5 program mode, press the SW2 button to select blue as the LED color.
* Selecting pink for the SW2 button LED saves it as Combined IR Mode, while selecting teal saves it as Combined White LED Mode.
When you cover the top of the device with your palm, the red LED lights up and the pattern begins to be saved.
Cover the light with your palm and open it to enter the pattern.
When the red LED turns off, the pattern is automatically saved.
After selecting SW5 transmission mode, select the blue LED where the pattern is saved with the SW2 button to transmit in synchronization mode.

Programming Sync Mode

■ Receiving unit

Power ON in basic setting mode
SW4 receiving mode is located.
If you select blue LED with SW2 button, synchronization mode is received.

Product specifications

Product Name : Spaver Signaty X IR Helmet Light

Manufacturer: PostX Co., Ltd. (Product and A/S Inquiries: 1661-5915)

Size: 90 x 59 x 36mm / Weight: 109g (including AA battery, molle clip)

Country of manufacture: Korea

Certification information

This product is certified through MIL-STD-810G testing procedures for operating and storage temperature, sand and dust, immersion, drop, and KC standards.

Name of certified person: PostX Co., Ltd.
