Signaty
Signaty V IR Helmet Light
Buy Now
Spaver Signaty, Made in Korea
Spaver
V IR Helmet Light
Signaty V1

Spaver Signaty V IR Helmet Light

Signaty V IFF IR Helmet Light

  • 5 Color LED (IR, Red, Green, Blue, White)
  • 9 lamps of 5 colors (IR x 4, RGB LED x 2, White LED x 2,
    High brightness white LED x 1
  • High strength polycarbonate dome cover material applied
  • Pattern programming using CDS without additional equipment
  • Up to 5km visibility with LED and NIR

Signaty V1

Spaver Signaty V IR Helmet Light

IR light made with Korean technology

  • Synchronization using short-range communication method for both outdoor and indoor environments.
  • Five group-specific strobe and strobe auto-sync function
  • Stores 4 flash patterns with automatic sync via programming
  • Able to operate with one hand, vibration feedback for confirmation
  • Distress beacon(SOS signal in Red LED or IR) and frontal high brightness flashlight mode
  • Up to 130 hours of operation using AA batteries (LED 130H / IR 125H)
  • Low voltage detection feature
  • Korea Domestic production and A/S

Signaty V1

Spaver Signaty V IR Helmet Light

Developed with Korean technology

  • Brightness and duration : LED 130 hours, IR 125 hours (In-house tested)
  • Visibility: Based on Internal test results (up to 5km)
  • Drop : KS C IEC 60068-2-31 (1.5m)
  • Waterproof : MIL-STD-810G 512.5 (1m 1hr)
  • Dustproof/Dust : MIL-STD-810G:2008 METHOD 510.5 PROCEDURE I (Dust)
  • Dustproof/Sand : MIL-STD-810G:2008 METHOD 510.5 PROCEDURE II (Sand)
  • High temperature storage/operation : MIL-STD-810G METHOD 501.5
    PROCEDURE I (23~63℃)/PROCEDURE II (23~43℃)
  • High temperature storage/operation : MIL-STD-810G METHOD 502.5
    PROCEDURE I (-33~23℃)/PROCEDURE II (-32~23℃)
  • KC Certified (BO5R392-2112B)

As of October 29, 2024

Brightness and duration

Inhouse tested (LED 130 hours, IR 125 hours)

Drop

KS C IEC 60068-2-31 (1.5m)

Waterproof/Dustproof

Waterproof : MIL-STD-810G 512.5 (1m 1hr)
Waterproof : KS C IEC 60529:2013 (1m 1hr)
MIL-STD-810G:2008 METHOD 510.5 PROCEDURE I Dustproof (Dust)
MIL-STD-810G:2008 METHOD 510.5 PROCEDURE II Dustproof (Sand)

High temperature storage/operation

MIL-STD-810G METHOD 501.5
PROCEDURE I (23~63℃)/PROCEDURE II (23~43℃)

Low temperature storage / operation

MIL-STD-810G METHOD 502.5
PROCEDURE I (-33~23℃)/PROCEDURE II (-32~23℃)

Test Passed

KC Certified
(BO5R392-2112B)

5

5 LED colors and IR

4

Stores 4 flash patterns

5

Flash function for 5 groups

5

Up to 5km distance

Manual Download
Catalogue Download

The default settings for starting and stopping the equipment are SW5 [●] Basic Mode and SW4 [○] LED Mode.

  • Power on/off : Press SW3 to turn on or off.
  • LED color change : Select SW4 as LED mode and press SW2 to change colors in the order of red > green > blue > white.
  • Change brightness : Shortly press the SW1 button. When pressed, it cycles in the following order: 10% > 30% > 60% > 100%.
  • Change pattern : Press and hold the SW1 button to cycle through the following order: 30 BPM > 50 BPM > Double Pulse > Strobe.
  • IR Mode : Select SW4 IR mode in default settings.
  • Flash mode : Select IR mode with SW4, basic mode with SW5, then press and hold SW2.

Quick light mode

■ Flash light mode

  • Select SW4 as IR mode and SW5 as basic mode, then press and hold SW2 to operate.

■ SOS Light Mode (RED LED)

  • While pressing SW1, press SW2 briefly 2 times to transmit an SOS pattern signal through the RED LED.

■ SOS Light Mode (IR LED)

  • While pressing SW1, press SW2 briefly 4 times. Sends out an SOS pattern signal using the IR LED.

Automatic synchronization mode

■ Transmitter

  • Power ON in basic setting mode
  • SW5 is in basic mode.
  • Set the color, brightness, and pattern of the SW4 LED mode or IR mode you want to transmit.
  • After selecting the SW5 transmission mode, press the SW2 button and select the yellow LED to transmit in synchronization mode.

■ Receiving unit

  • Power ON in basic setting mode
  • SW4 receiving mode is located.
  • Press the SW2 button and select the yellow LED to receive synchronization mode.

Programming Sync Mode

■ Transmitter

  • Power ON in basic setting mode
  • SW5 basic mode is located.
  • Set the color and brightness of the SW4 LED mode or IR mode you want to transmit.
  • Select programming mode with SW5, then press SW2 to choose the bank LED color to be saved.
  • When you cover the top of the device with your palm, the red LED lights up and the pattern begins to be saved.
  • Cover the light with your palm and open it to enter the pattern.
  • When the red LED turns off, the pattern is automatically saved.
  • After selecting SW5 transmission mode, select the blue LED where the pattern is saved with the SW2 button to transmit in synchronization mode.

Programming Sync Mode

■ Receiving unit

  • Power ON in basic setting mode
  • SW4 receiving mode is located.
  • Synchronization mode is activated when the same LED as the transmitter is selected using the SW2 button.

Product specifications

Product Name : Spaver Signaty IFF IR Helmet Light V

Manufacturer: PostX Co., Ltd. (Product and A/S Inquiries: 1661-5915)

Size: 90 x 59 x 34mm / Weight: 105g (including AA battery, molle clip)

Country of manufacture: Korea

Certification information

This product is certified through MIL-STD-810G testing procedures for operating and storage temperature, sand and dust, immersion, drop, and KC standards.

Name of certified person: PostX Co., Ltd.
